Promise VTrak E5000 Series

High Performance, High Availability

The VTrak E5000 Series delivers an affordable high-performance Fibre Channel to SAS storage solution with advanced enterprise level reliability and functionality. With four 16Gb Fibre Channel ports and two 12Gb SAS ports per controller connecting host and storage expansion, the E5000 is perfect for applications requiring huge bandwidth. The E5000 can output 542,100 read IOPs and up to 111,686 write IOPs. It can deliver 12 Gigabyte read and 5.3 Gigabyte write sequential throughput. Fully redundant components such as Active-Active controllers, power supplies, and cooling units provide optimal data availability even during unforeseen circumstances. The VTrak E5000 is truly a full featured enterprise level storage system that can accommodate any size of business environment.

IT/Data Center Ready

Fully compatible with 6 Gb/s SAS/SATA devices, the VTrak E5000 gives users the ability to deploy 6 Gb/s and 12 Gb/s SAS/SATA HDDS and SSDs. Efficient power supplies provide up to 90% improved power efficiency, improving TCO by conserving power, reducing heat output and lower cooling costs. The E5000’s flash arrays enable optimized speed for key enterprise applications that need high-speed transfer rates and reduced latency and thanks to its Intel multi-core Broadwell-DE based architecture providing ample processing power to achieve transfer speeds at line rate on both 16Gb Fibre Channel front-end interfaces and 12Gb SAS backend interfaces.

Virtualization Ready

Ready to confront any challenge in today’s virtualized IT environment, the VTrak E5000 Series is certified with VMware vSphere, Citrix XenServer, Microsoft Hyper-V, Veeam, and DataCore SANsymphony.

Virtualization enables dynamic storage allocations such that physical layers of storage can be utilized most effectively. As virtual machines continue to increase with more virtualized deployments, 16Gb Fibre Channel performance delivers the faster bandwidth needed for growing infrastructures.

FEATURES

  • VTrak E5000 Series 16 Gb/s Fibre Channel to SAS subsystems deliver a high performance SAS solution with advanced enterprise level reliability and functionality
  • 24 hot-swappable 2.5” (LFF) drive bays in a 2U chassis
  • Supports SAS and SATA drives simultaneously and is compatible with leading SAS & SATA drives, HBAs, and RAID controllers
  • Dual active/active controllers with ALUA for performance and access flexibility
  • Quad 16Gb FC ports and dual 12Gb SAS ports per controller for connecting host and storage expansion

SPECIFICATIONS

Form Factor
2U/24 Bay
Drive Support
Up to 24 x 2.5″ drives
  • 6/12 Gb SAS, 6 Gb SATA HDD and SSD
  • Supports any mix of SAS and SATA drives simultaneously in the same enclosure
External I/O Ports (per controller)
Each SBB2.0 RAID Controller has four 16 Gb FC SFP ports for Host interface and two 12 Gb SAS standard Mini SAS HD ports (SFF-8644) for Storage Expansion, RJ45 1Gb Ethernet and RS232 for Management ports
RAID Levels
0, 1 , 5, 6, 10, 50, 60
RAID Stripe Size Support
64K, 128K, 256K, 512K and 1MB
Hot Spares
Global or dedicated with revertible option
Max LUNs per Subsystem
1024
Max LUNs per system/array
32
Advanced Storage Features
  • Advanced Cache Mirroring over PCIe Gen3
  • Simple, drag-and-drop LUN Masking and Mapping
  • Asymmetric LUN Unit Access (ALUA)
  • Volume Copy
  • PerfectFlash – Non-Disruptive Software Update
  • I/O performance & power monitoring tools
  • USB Service Log
  • LDAP Support for central user management
Background Activities
  • Media Patrol
  • Background Synchronization
  • Foreground Initialization
  • Rebuild
  • Redundancy Check
  • Disk SMART Polling
  • Online Capacity Expansion (OCE)
  • RAID Level Migration (RLM)
  • UPS Monitoring
  • Feature rich task scheduler for background activities
PerfectRAID Features
  • Predictive Data Migration (PDM)
  • Intelligent Bad Sector Remapping
  • SMART Error Handling
  • NVRAM Error Logging
  • Disk Slot Power Control
  • Read/Write Check Table
  • Write Hole Table
GreenRAID Features
  • Four levels of advanced power management disk drive (MAID) support
  • Efficient 80Plus Certified power supplies
Management Interfaces
  • Web Based management using WebPAM PROe (Ethernet)
  • Command Line Interface (CLI)
  • Third Party Management Support via SNMP, CIM
Supported Operating Systems
Windows Server 2008, 2012, HyperV, OS X 10.x, RHEL 6.5, 6.6, SLES 11, VMWare ESX v6.x
Voltage
100–240 Vac Auto–Ranging
Current (Maximum)
9A @ 100 Vac; 4A @ 240 Vac
Power Conversion Efficiency
>80% @ 110V (>20% load), >80% @ 240V (>20% load) Temperature Range
Temperature Range
Operational: 5° to 40°C, Non-Operational: -40° to 60°C
Humidity
Operational: 10% to 90% (Non-Condensing), Non–Operational: 5% to 95% (Non-Condensing)
Acoustic Noise Levels
55 dB (Typical), 65 dB (Maximum)
Shock
Operational: 5G, 11 ms duration, Non-Operational: 10G, 11ms duration
Vibration
Operational: 0.3G, 5 to 500 Hz, Non-Operational: 1G, 5 to 500 Hz
Safety and Emission Certification
EMC Class A: CE, FCC, VCCI, BSMI, RCM and KC Safety: IEEE CB, UL/cUL and TUV
Environmental Standards
RoHS, GreenPC, WEEE
Power Supply
Efficient 80PLUS GOLD Certified redundant PSU
Dimensions
(H x W x D) 88 x 446.7 x 420 mm (3.5″ x 17.6″ x 16.5″)
Weight
13.8 Kg (30.4 lbs) w/o drives, 19.2 Kg (43.3 lbs) w/ drives
Warranty
3-year full system limited warranty, optional extended warranty, onsite parts replacement program
Support
24/7 e-mail and phone support, 24/7 access to PROMISE site-drives, firmware, and compatibility list

FEATURES

  • VTrak E5000 Series 16 Gb/s Fibre Channel to SAS subsystems deliver a high performance SAS solution with advanced enterprise level reliability and functionality
  • 12 hot-swappable 3.5” (LFF) drive bays in a 2U chassis
  • Supports SAS and SATA drives simultaneously and is compatible with leading SAS & SATA drives, HBAs, and RAID controllers
  • Dual active/active controllers with ALUA for performance and access flexibility
  • Quad 16Gb FC ports and dual 12Gb SAS ports per controller for connecting host and storage expansion

SPECIFICATIONS

Form Factor
2U/12 Bay
Drive Support
Up to 12 x 3.5″ drives
  • 6/12 Gb SAS, 6 Gb SATA HDD and SSD
  • Supports any mix of SAS and SATA drives simultaneously in the same enclosure
External I/O Ports (per controller)
Each SBB2.0 RAID Controller has four 16 Gb FC SFP ports for Host interface and two 12 Gb SAS standard Mini SAS HD ports (SFF-8644) for Storage Expansion, RJ45 1Gb Ethernet and RS232 for Management ports
RAID Levels
0, 1 , 5, 6, 10, 50, 60
RAID Stripe Size Support
64K, 128K, 256K, 512K and 1MB
Hot Spares
Global or dedicated with revertible option
Max LUNs per Subsystem
1024
Max LUNs per system/array
32
Advanced Storage Features
  • Advanced Cache Mirroring over PCIe Gen3
  • Simple, drag-and-drop LUN Masking and Mapping
  • Asymmetric LUN Unit Access (ALUA)
  • Volume Copy
  • PerfectFlash – Non-Disruptive Software Update
  • I/O performance & power monitoring tools
  • USB Service Log
  • LDAP Support for central user management
Background Activities
  • Media Patrol
  • Background Synchronization
  • Foreground Initialization
  • Rebuild
  • Redundancy Check
  • Disk SMART Polling
  • Online Capacity Expansion (OCE)
  • RAID Level Migration (RLM)
  • UPS Monitoring
  • Feature rich task scheduler for background activities
PerfectRAID Features
  • Predictive Data Migration (PDM)
  • Intelligent Bad Sector Remapping
  • SMART Error Handling
  • NVRAM Error Logging
  • Disk Slot Power Control
  • Read/Write Check Table
  • Write Hole Table
GreenRAID Features
  • Four levels of advanced power management disk drive (MAID) support
  • Efficient 80Plus Certified power supplies
Management Interfaces
  • Web Based management using WebPAM PROe (Ethernet)
  • Command Line Interface (CLI)
  • Third Party Management Support via SNMP, CIM
Supported Operating Systems
Windows Server 2008, 2012, HyperV, OS X 10.x, RHEL 6.5, 6.6, SLES 11, VMWare ESX v6.x
Voltage
100–240 Vac Auto–Ranging
Current (Maximum)
9A @ 100 Vac; 4A @ 240 Vac
Power Conversion Efficiency
>80% @ 110V (>20% load), >80% @ 240V (>20% load) Temperature Range
Temperature Range
Operational: 5° to 40°C, Non-Operational: -40° to 60°C
Humidity
Operational: 10% to 90% (Non-Condensing), Non–Operational: 5% to 95% (Non-Condensing)
Acoustic Noise Levels
55 dB (Typical), 65 dB (Maximum)
Shock
Operational: 5G, 11 ms duration, Non-Operational: 10G, 11ms duration
Vibration
Operational: 0.3G, 5 to 500 Hz, Non-Operational: 1G, 5 to 500 Hz
Safety and Emission Certification
EMC Class A: CE, FCC, VCCI, BSMI, RCM and KC
Safety: IEEE CB, UL/cUL and TUV
Environmental Standards
RoHS, GreenPC, WEEE
Power Supply
Efficient 80PLUS GOLD Certified redundant PSU
Dimensions
(H x W x D) 88 x 446.7 x 507 mm (3.5″ x 17.6″ x 19.96″)
Weight
14.8 Kg (32.6 lbs) w/o drive, 24.8 Kg (54.7 lbs) w/ drives
Warranty
3-year full system limited warranty, optional extended warranty, onsite parts replacement program
Support
24/7 e-mail and phone support, 24/7 access to PROMISE site-drives, firmware, and compatibility list

FEATURES

  • VTrak E5000 Series 16 Gb/s Fibre Channel to SAS subsystems deliver a high performance SAS solution with advanced enterprise level reliability and functionality
  • 16 hot-swappable 3.5” (LFF) drive bays in a 3U chassis
  • Supports SAS and SATA drives simultaneously and is compatible with leading SAS & SATA drives, HBAs, and RAID controllers
  • Dual active/active controllers with ALUA for performance and access flexibility
  • Quad 16Gb FC ports and dual 12Gb SAS ports per controller for connecting host and storage expansion

SPECIFICATIONS

Form Factor
3U/16 Bay
Drive Support
Up to 16 x 3.5″ drives
  • 6/12 Gb SAS, 6 Gb SATA HDD and SSD
  • Supports any mix of SAS and SATA drives simultaneously in the same enclosure
External I/O Ports (per controller)
Each SBB2.0 RAID Controller has four 16 Gb FC SFP ports for Host interface and two 12 Gb SAS standard Mini SAS HD ports (SFF-8644) for Storage Expansion, RJ45 1Gb Ethernet and RS232 for Management ports
RAID Levels
0, 1 , 5, 6, 10, 50, 60
RAID Stripe Size Support
64K, 128K, 256K, 512K and 1MB
Hot Spares
Global or dedicated with revertible option
Max LUNs per Subsystem
1024
Max LUNs per system/array
32
Advanced Storage Features
  • Advanced Cache Mirroring over PCIe Gen3
  • Simple, drag-and-drop LUN Masking and Mapping
  • Asymmetric LUN Unit Access (ALUA)
  • Volume Copy
  • PerfectFlash – Non-Disruptive Software Update
  • I/O performance & power monitoring tools
  • USB Service Log
  • LDAP Support for central user management
Background Activities
  • Media Patrol
  • Background Synchronization
  • Foreground Initialization
  • Rebuild
  • Redundancy Check
  • Disk SMART Polling
  • Online Capacity Expansion (OCE)
  • RAID Level Migration (RLM)
  • UPS Monitoring
  • Feature rich task scheduler for background activities
PerfectRAID Features
  • Predictive Data Migration (PDM)
  • Intelligent Bad Sector Remapping
  • SMART Error Handling
  • NVRAM Error Logging
  • Disk Slot Power Control
  • Read/Write Check Table
  • Write Hole Table
GreenRAID Features
  • Four levels of advanced power management disk drive (MAID) support
  • Efficient 80Plus Certified power supplies
Management Interfaces
  • Web Based management using WebPAM PROe (Ethernet)
  • Command Line Interface (CLI)
  • Third Party Management Support via SNMP, CIM
Supported Operating Systems
Windows Server 2008, 2012, HyperV, OS X 10.x, RHEL 6.5, 6.6, SLES 11, VMWare ESX v6.x
Voltage
100–240 Vac Auto–Ranging
Current (Maximum)
9A @ 100 Vac; 4A @ 240 Vac
Power Conversion Efficiency
>80% @ 110V (>20% load), >80% @ 240V (>20% load) Temperature Range
Temperature Range
Operational: 5° to 40°C, Non-Operational: -40° to 60°C
Humidity
Operational: 10% to 90% (Non-Condensing), Non–Operational: 5% to 95% (Non-Condensing)
Acoustic Noise Levels
55 dB (Typical), 65 dB (Maximum)
Shock
Operational: 5G, 11 ms duration, Non-Operational: 10G, 11ms duration
Vibration
Operational: 0.3G, 5 to 500 Hz, Non-Operational: 1G, 5 to 500 Hz
Safety and Emission Certification
EMC Class A: CE, FCC, VCCI, BSMI, RCM and KC
Safety: IEEE CB, UL/cUL and TUV
Environmental Standards
RoHS, GreenPC, WEEE
Power Supply
Efficient 80PLUS GOLD Certified redundant PSU
Dimensions
(H x W x D) 131 x 446.7 x 507 mm (5.2″ x 17.6″ x 19.96″)
Weight
25 Kg (56 lbs) w/o drives, 38.3 Kg (84 lbs) w/ drives
Warranty
3-year full system limited warranty, optional extended warranty, onsite parts replacement program
Support
24/7 e-mail and phone support, 24/7 access to PROMISE site-drives, firmware, and compatibility list

FEATURES

  • VTrak E5000 Series 16 Gb/s Fibre Channel to SAS subsystems deliver a high performance SAS solution with advanced enterprise level reliability and functionality
  • 24 hot-swappable 3.5” (LFF) drive bays in a 4U chassis
  • Supports SAS and SATA drives simultaneously and is compatible with leading SAS & SATA drives, HBAs, and RAID controllers
  • Dual active/active controllers with ALUA for performance and access flexibility
  • Quad 16Gb FC ports and dual 12Gb SAS ports per controller for connecting host and storage expansion

SPECIFICATIONS

Form Factor
4U/24 Bay
Drive Support
Up to 24 x 3.5″ drives
  • 6/12 Gb SAS, 6 Gb SATA HDD and SSD
  • Supports any mix of SAS and SATA drives simultaneously in the same enclosure
External I/O Ports (per controller)
Each SBB2.0 RAID Controller has four 16 Gb FC SFP ports for Host interface and two 12 Gb SAS standard Mini SAS HD ports (SFF-8644) for Storage Expansion, RJ45 1Gb Ethernet and RS232 for Management ports
RAID Levels
0, 1 , 5, 6, 10, 50, 60
RAID Stripe Size Support
64K, 128K, 256K, 512K and 1MB
Hot Spares
Global or dedicated with revertible option
Max LUNs per Subsystem
1024
Max LUNs per system/array
32
Advanced Storage Features
  • Advanced Cache Mirroring over PCIe Gen3
  • Simple, drag-and-drop LUN Masking and Mapping
  • Asymmetric LUN Unit Access (ALUA)
  • Volume Copy
  • PerfectFlash – Non-Disruptive Software Update
  • I/O performance & power monitoring tools
  • USB Service Log
  • LDAP Support for central user management
Background Activities
  • Media Patrol
  • Background Synchronization
  • Foreground Initialization
  • Rebuild
  • Redundancy Check
  • Disk SMART Polling
  • Online Capacity Expansion (OCE)
  • RAID Level Migration (RLM)
  • UPS Monitoring
  • Feature rich task scheduler for background activities
PerfectRAID Features
  • Predictive Data Migration (PDM)
  • Intelligent Bad Sector Remapping
  • SMART Error Handling
  • NVRAM Error Logging
  • Disk Slot Power Control
  • Read/Write Check Table
  • Write Hole Table
GreenRAID Features
  • Four levels of advanced power management disk drive (MAID) support
  • Efficient 80Plus Certified power supplies
Management Interfaces
  • Web Based management using WebPAM PROe (Ethernet)
  • Command Line Interface (CLI)
  • Third Party Management Support via SNMP, CIM
Supported Operating Systems
Windows Server 2008, 2012, HyperV, OS X 10.x, RHEL 6.5, 6.6, SLES 11, VMWare ESX v6.x
Voltage
100–240 Vac Auto–Ranging
Current (Maximum)
9A @ 100 Vac; 4A @ 240 Vac
Power Conversion Efficiency
>80% @ 110V (>20% load), >80% @ 240V (>20% load) Temperature Range
Temperature Range
Operational: 5° to 40°C, Non-Operational: -40° to 60°C
Humidity
Operational: 10% to 90% (Non-Condensing), Non–Operational: 5% to 95% (Non-Condensing)
Acoustic Noise Levels
55 dB (Typical), 65 dB (Maximum)
Shock
Operational: 5G, 11 ms duration, Non-Operational: 10G, 11ms duration
Vibration
Operational: 0.3G, 5 to 500 Hz, Non-Operational: 1G, 5 to 500 Hz
Safety and Emission Certification
EMC Class A: CE, FCC, VCCI, BSMI, RCM and KC
Safety: IEEE CB, UL/cUL and TUV
Environmental Standards
RoHS, GreenPC, WEEE
Power Supply
Efficient 80PLUS GOLD Certified redundant PSU
Dimensions
(H x W x D) 174.4 x 446.7 x 507 mm (6.87″ x 17.6″ x 19.96″)
Weight
29.6 Kg (64 lbs) w/o drives, 49.6 Kg (108 lbs) w/ drives
Warranty
3-year full system limited warranty, optional extended warranty, onsite parts replacement program
Support
24/7 e-mail and phone support, 24/7 access to PROMISE site-drives, firmware, and compatibility list

Request for more information by contacting us now

Email: [email protected] or Call: 03 8806 8356
